Graphic Card
| Model | DUAL-RTX5060-O8G |
|---|---|
| Graphics Engine | NVIDIA® GeForce RTX™ 5060 |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 3,840 |
| AI Performance | Up to 614 TOPs |
| Video Memory | 8GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| Bus Standard | PCI Express 5.0 |
| Boost Clock | 2,535 MHz |
| OC Mode | 2,565 MHz |
| OpenGL | OpenGL 4.6 |
| Max Resolution | 7680 × 4320 |
| HDMI | 1 × HDMI 2.1b |
| DisplayPort | 3 × DisplayPort 2.1b |
| Maximum Displays | 4 |
| HDCP | 2.3 |
| Cooling | ASUS Axial-Tech Fan Design |
| Fans | 2 Fans |
| Slot | 2.5-Slot |
| Power Connector | 1 × 8-pin |
| Recommended PSU | 550W |
| Dimensions | 228 × 123 × 50 mm |
| SFF Ready | Yes |
| Brand | asus |
| Warranty | 3 Years Official Warranty |
| Graphics-engine | NVIDIA® GeForce RTX™ 5060 |
| Cuda-cores | 3,840 |
| Ai-performance | Up to 614 TOPs |
| Video-memory | 8GB GDDR7 |
| Memory-speed | 28 Gbps |
| Memory-interface | 128-bit |
| Bus-standard | PCI Express 5.0 |
| Boost-clock | 2,535 MHz |
| Oc-mode | 2,565 MHz |
| Opengl | OpenGL 4.6 |
| Max-resolution | 7680 × 4320 |
| Hdmi | 1 × HDMI 2.1b |
| Displayport | 3 × DisplayPort 2.1b |
| Maximum-displays | 4 |
| Hdcp | 2.3 |
| Power-connector | 1 × 8-pin |
| Recommended-psu | 550W |
| Sff-ready | Yes |
Advanced cooling systems engineered for silent operations and high processing workloads.
